Features & Benefits:
- Rigid high strength 3/16” steel box frame with heavy bar reinforcement
- 2 position tilt handle bars
- Push or self propelled drive
- Screw feed raise and lower with optional power raise and lower
- Cyclone air filter on gas models
- Positive gear drive to rear axle via Eaton hydrostatic transmission
Specifications:
| Maximum depth of cut with 14” blade: | 4-5/8” |
| Maximum depth of cut with 20” blade: | 7-3/8” |
| Maximum depth of cut with 26” blade: | 10-3/8” |
| Blade shaft RPM: | Varies |
| Blade shaft diameter: | 1-1/2” |
| Arbor size: | 1” w/drive pin |
| Blade shaft drive: | 4 belt up to 20.8HP, 5 belt for 25HP |
| Blade mounting: | Right or Left |
| Transmission (self propelled only): | Eaton Model 7 |
| Drive Speed: | 0-130 feet/min |
| Fuel Capacity (gas models): | 5 gallons |
INCLUDES:
Electric Start (20-25 HP models) Low Oil Alert Tach/Hour Meter (20-25 HP models) Frame Lift Quick Disconnect Blade Flanges Cutting Depth Indicator Telescoping front pointer
